    SYF-A Computer High Speed Slitting Machine ( Three vector motor control )

    This machine is used for slitting and rewinding various large rollingmaterials such as paper, (50g/m2~300g/m2)Kraft paper, coated paper,aluminum foil, PVC, plastic material, etc.

    PERFORMANCE AND CHARACTERISTICS

    This machine is used for slitting and rewinding various large rolling materials such as paper,(50g/m2~300g/m2)Kraft paper, coated paper,aluminum foil, PVC, plastic material, etc.

    1. This machine adopts PLC touch screen control. Three motor vector control and automatic taper tension, central surface reeling. Frequency converter timing for main motor, keeping speed up and stable operation.
    2. It has the functions of auto metering, automatic alarm, etc. Adopt Aand B pneumatic shaft structure for rewinding, easy for loading and unloading.
    3. It adopts photoelectric automatic error correction adjustment system for unwinding, anomalistic materials will be easy slit.
    4. Equipped with automatic waste film blowing device.
    5. Hydraulic shaftless loading system (can use automatic loading by phneumatic as optional )

    PERFORMANCE AND CHARACTERISTICS

    ModelSYF-1100ASYF-1300ASYF-1600A
    Max. Width of unwinding1100 mm1300 mm1600 mm
    Max. Diameter of unwindingΦ1400/1600 mmΦ1400/1600 mmΦ1400/1600 mm
    Min. Width of slitting50 mm50 mm50 mm
    Max. Diameter of rewindingΦ1000/1200 mmΦ1000/1200 mmΦ1000/1200 mm
    Speed10–450 m/min10–450 m/min10–450 m/min
    Total power22 kW22 kW24 kW
    Power supply380V / 50Hz380V / 50Hz380V / 50Hz
    Weight5600 kg6000 kg6400 kg
    Overall dimension (L×W×H)4200×3200×1950 mm4200×3400×1950 mm4200×3700×1950 mm
