    SYH-B Automatic High-Precision Cross Cutting Machine With Stacker

    This machine is suitable for horizontal and vertical cutting rolling materials such as,chrome paper, coated paper and kraft paper, etc. It's much more suitable for production of paper making and paper,and printing packaging process industry.

    PERFORMANCE AND CHARACTERISTICS

    This machine is suitable for horizontal and vertical cutting rolling materials such as,chrome paper, coated paper and kraft paper, etc. It’s much more suitable for production of paper making and paper,and printing packaging process industry.

    1. Adopts pneumatic automatic materials loading system with much easy operation and convenience.
    2. Adopts imported heavy vertical type cutters with orderly finished products and without water caltrop; meantime, it can be used for horizontal cutting and vertical cutting at one time ( Optional device ).
    3. It has the function of automatic stacking which is in order.Photoelectric auto tracing subtense system.
    4. Photo eletric tracking suits for printing material ( Optional device ).

    PERFORMANCE AND CHARACTERISTICS



    ModelSYH-1100BSYH-1400B
    Max cutting width1100 mm1400 mm
    Max diameter of unwindingΦ1400 mmΦ1400 mm
    Cutting length200-1200 mm200-1200 mm
    Cutting speed10-180 times/min10-180 times/min
    Cutting precision±0.2mm±0.2mm
    Range of raw material thickness80-500 g/㎡80-500 g/㎡
    Height of stackingMax. 1000 mmMax. 1000 mm
    Total power11kw11kw
    Weight (approx.)4200kg4500kg
    Overall dimension (L×W×H)5700×2100×1750 mm5700×2300×1750 mm
